ZEONET®PB是FKM(氟橡胶)和NBR(丁腈橡胶)的硫化型粘合剂。
FKM | |
---|---|
Viton® VTR9160 | 100 |
Bisphenol F | Originally contained in Viton® VTR9160 |
MgO | 6 |
Ca(OH)2 | 6 |
Carbon black: N762 | 15 |
PVC modified NBR | ||
---|---|---|
Sulfur cure | Peroxide cure | |
Nipol® DN508 | 100 | 100 |
ZnO#1 | 5 | 5 |
Stearic acid | 1 | 1 |
Carbon black: N990 | 30 | 30 |
Nipsil VN3 | 15 | 15 |
Thiokol TP95 | 15 | 15 |
A.O.224 | 2 | 2 |
Wax | 2 | 2 |
Sulfur | 1.5 | - |
TMTD |
0.5 | - |
MBTS | 1.5 | - |
Percumil D-40 | - | 2 |
NBR cure system | Sulfur | Peroxide | ||
---|---|---|---|---|
ZEONET® PB for NBR cure | 0 | 3PHR | 0 | 3PHR |
Failure mode at peeling test | A.F. | M.B. | A.F. | M.B. |
NBR cure system | Sulfur | Peroxide | |||
---|---|---|---|---|---|
ZEONET® PB for NBR cure | 0 | 3PHR | 0 | 3PHR | |
Mooney Scorch @125 degrees C t5 (min.) |
16.2 | 4.8 | 11.4 | 9.7 | |
Tensile properties |
Tensile Strength (MPa) | 15.6 | 17.2 | 16.4 | 17.3 |
Elongation (%) | 420 | 190 | 280 | 470 | |
100% Modulus (MPa) | 3.3 | 8.2 | 4.2 | 3.5 | |
Hardness (Shore A) | 71 | 77 | 37 | 44 | |
Compression Set (%) 70hr.s at 100 degrees C |
47 | 67 | 37 | 44 |
